Hello to the World of Python-Bridge

This Hello World guide introduces the AIMMS Python-Bridge, focusing on the core “Python-in-the-lead” workflow.

Specifically, the Python script will manage the AIMMS application to:

• Open and manage an AIMMS application instance.

• Exchange data (read and write) with the AIMMS model.

• Execute AIMMS procedures.

Please use the Hello World project to follow this article.

Prerequisites & Environment Setup

To ensure reproducibility and manage dependencies, this tutorial focuses on using a specific Python version within an isolated virtual environment.

Note

This tutorial focuses on a specific environment setup for reproducibility. Other configurations are possible but are outside the scope of this article.

Install Dependency Tools

If you haven’t already, please install the recommended dependency management tools:

1. pyenv (for managing Python versions): pyenv (for Linux/macOS) or pyenv-win (for Windows).

2. uv (for fast package and environment management): uv.

Initialize the Environment

Start a PowerShell or terminal, navigate to the directory containing the Python main.py file, and execute the following commands:

pyenv install 3.13
pyenv local 3.13
uv init
uv venv
.venv\Scripts\activate

Remarks:

• Lines 1-2: Set Python 3.13 as the interpreter for the current directory.

• Lines 3-4: Initialize the project and create a new virtual environment (.\venv).

• Line 5: Activate the newly created virtual environment.

Hint

If you face an error while pyenv install 3.13, use pyenv install --list to see all available python versions. And, if you don’t find the Python version you’d like to use, please run pyenv update and try again.

Install Dependencies

uv pip install -r requirements.txt

Remarks:

• By convention, requirements.txt enumerates the Python libraries necessary to install for the project at hand.

AIMMS Model

The accompanying AIMMS model, hello.aimms, is intentionally simple. It defines an input array (p_A) and calculates the scalar sum of its elements, storing the result in an output parameter (p_B).

Fig. 56 AIMMS Model Explorer showing input parameter p_A and output parameter p_B.

Fig. 57 AIMMS procedure MainExecution containing a single assignment statement.

Python Script

The Python script uses the aimmspy library to control the AIMMS session.

# Import necessary classes and functions.
from aimmspy.project.project import Project, Model
from aimmspy.utils import find_aimms_path

# Initialize the AIMMS project
project = Project(

    # Path to the AIMMS Bin folder
    aimms_path=find_aimms_path("25"),

    # Path to the AIMMS project file (relative to the script).
    #aimms_project_file=projectfile,
    aimms_project_file = "..\\AIMMS\\hello.aimms",

    # Optional: Add your licensing URL here.
)
aimms_model : Model = project.get_model(__file__)

# Send data to the AIMMS model
hello_world_dict = { "hello" : 1, "world" : 2 }
aimms_model.p_a.assign( hello_world_dict )

# Run an AIMMS procedure
aimms_model.MainExecution()

# Get results back and print.
hello_world_result = aimms_model.p_b.data()
print(f"Hello world: sum is {hello_world_result}")

Expected Output

The script can now be executed using:

uv run main.py

When the script is executed, the AIMMS session opens, data is exchanged, and the result is returned to Python:

C:\Users\ChrisKuip\AppData\Local\AIMMS\IFA\Aimms\25.7.7.4-x64-VS2022\Bin --as-server "..\AIMMS\hello.aimms"
Hello world: sum is 3.0
